NGC 6188 (partial) & 6193 – EMISION NEBULA & OPEN CLUSTER

Ara

(ra: 16h 41m 09s/ dec -48º 48' 00'')

For the Ha Version click here

DATA

TYPE: Bright Reflection Nebula and Open cluster

VISUAL BRIGHTNESS: NGC 6193: 5.2 (visual); NGC 6188 N/A

SIZE: NGC 6193 14 arcs seconds; NGC 6188 x 20 x 12 arc minutes

DISTANCE: 4000 light years

OBJECT DESCRIPTION (*)

NGC 6188 is one of the most beautiful emission nebula of the sky. The region gathers young blue stars, hot red gas and cool dark dust.  Is the home of a group of young stars which forms the open cluster NGC 6193. Its stars are so bright that reflects interstellar dust forming a diffuse blue glow which is nearly visible in the photograph.

The object was too low in the horizon and this photograph is in fact a test image to see what the object responds to the SXVF H9 and the C8. Not much exposure but is quite a promising target for the next weeks.

IMAGE INFORMATION

SCOPE: Celestron SCT 8" at @ f7 (roughly)

MOUNT: Vixen GPDX SkySensor 2000

SKY CONDITIONS: full moon

CAMERA: Starlight Xpress SXVF H9

FILTERS: Astronomik Type II & Ha 6nm

EXPOSURES: LHRGB (20,20,8,8,8) L and Ha 240 secs RGB Two minutes Subs

IMAGE ACQUISITION: AstroArt v 3. CCD control Interface v. 3.72

GUIDING: Synta 70/400 refractor - SXV Guide Camera - Astro Art 3.0 CCD Control Interface Plug In

PROCESSED: Calibrated with Images Plus (no darks, nor bias used), Photoshop CS

(*) Source Internet

NGC 6188 (partial) & 6193 – IN Ha

Ara

(ra: 16h 41m 09s/ dec -48º 48' 00'')
