PK 42-4.1 AKA ABELL 62

AQUILA

 (ra: 19.33,2/ dec -10:37')

August 2009, Home Backyard in Martínez - Buenos Aires, Argentina

DATA

TYPE: Planetary Nebula

Apparent Magnitude: 14.7

Surface Brightness 16.78

Apparent Diameter: 161 x 151 arc seconds

DISTANCE: not found

IMAGE INFORMATION

SCOPE: Celestron SCT 8" working at f5

CAMERA: SXVF H9

GUIDING: William Optics ZenithStar 66

IMAGE ACQUISITION: AstroArt 3.0 - Control Interface 3.72 plug in

FILTERS: Astronomik Type II - Astronomik Ha 6 nm - Atik Filter Wheel

SKY CONDITIONS: urban skies - transparency and seeing regular

EXPOSURES: HaRGB (20,20,20,20) all binned 2X2

PROCESSING: Images Plus, CCD Sharp, Photoshop CS2

OBJECT DESCRIPTION AND IMAGE SESSION

This is the faintest object I have imaged so far. A very dim planetary nebula located in the Constellation of Aquila. The object was selected because its diameter and I believe it is not visible with regular telescopes. At least no trace of the PN while shooting RGB. Not much information nor pictures of this object. Nevertheless it was interesting to see the capabilities of the SXV H9 under urban skies.

PK designations stands for Czechoslovakian astronomers Perek & Kohoutek  who publish a catalog of Planetary Nebulas in 1967

The picture was taken in bin 2x2 to get more light and then re sampled to 1392 x 1040 pixeles for processing. Finally the JPG file was reduced a bit for aesthetical purposes.
